Page 26 - Machine installation instructions
P. 26
EN
Symptom Cause Solution
Mowing time is too short Reset and increase mowing time
Trying to reduce work area or
Mowing more lawn than claimed
increase mowing time
The blade is not sharp enough Try replacing all the blades
Try raising the cutting height and then
Cutting height set too low adjusting to the desired cutting height
Grass is being cut unevenly in 2cm steps.
The cutting disc is surrounded by Inspect the cutterhead and remove
any other objects that may be
grass clippings
blocking the cutterhead rotation.
"Remove the obstacles, such as piles
Recognition error of leaves, weeds
and wildffowers."
Placement of magnetic strips or
There are chain obstacles in the lawn physical separation boundaries
around continuous obstacles
The mower stops within the working Grass stuck at the bottom of the Regularly clean the bottom blade of
area
blade the machine
The machine cutting height is set too Raise cutting height and slowly lower
low to desired height
There are obstacles between the Clearance of obstacles in the
tags in the pathway passageway
Ensure that the magnetic marker
is installed correctly. Refer to
The secondary area is not mowed The intallation of the tags is incorrect
the Magnetic Label Installation
Instructions section.
System problem. Please contact
System error
after-sales
Check and clean the dirt from the
Machine wheels slipping
wheels
Use magnetic strips to fence off the
Slope greater than 42% (22°) bottom of the slope or set a 5cm non-
grass border
There are large patches of baldness
and yellow grass on the lawn border,
Problems with identification which need to be separated by
magnetic strips or other physical
boundaries
Clear the grass, tall grass, and weeds
The mower is out of the working area along the border to ensure a 5cm
Borders covered with grass non-grass border. Alternatively, set
up a fence that is higher than the
lawn.
Check the installation of the magnetic
stripe to ensure that the gap between
the two ends of the magnetic stripe
There is a problem with the magnetic does not exceed 10cm, the gap
stripe arrangement between the magnetic stripe and the
physical boundary is less than 15cm,
and the magnetic stripe is not buried
by soil
25
