Page 20 - Machine installation instructions

EN

C. Dry the sensor area after cleaning to prevent it from
being triggered as it would be by rain.

Camera
Clean the camera regularly to keep it clean.

WARNING
- Make sure that the mower is powered off before
cleaning.
- When the mower is upside down, turn it off.

6.2 Replace Blades

For improved mowing performance and safety, it is
recommended to change the mower's screws and blades
every 1-2 months if it is used frequently. For a safe cutting
system, replace all blades along with their screws at the
same time.

WARNING

- When inspecting or servicing the blade, wear thick
gloves.
- DO NOT reuse the screws. Serious injury may
result from doing this.
- We strongly advise using the correct screws
and original blades that have been sold by us.
(NO.80201457-02).

How to replace blades
A. Turn off the mower.
B. Set the mower upside-down on a spotless, soft surface
to prevent scratches.
C. Use a cross-tip screwdriver to loosen the screws.
D. Remove the screws and blades.
E. Fasten the new blades and screws (Torque: 1.0+0.2 N.m).
Make sure that the blades can pivot freely.

NOTE
- Replace the screws with a standard torque of 1.0+0.2 N.m.
Incorrect torque may lead to avoidable issues.
- Ensure that the mower is turned off and check the blades
for proper application. Check for abnormal noise or shaking.

19
